The NG-RAN (Next Generation Radio Access Network) is a key component of 5G networks, providing the radio access and connectivity between user devices and the core network. The NG-RAN architecture is based on a split between the Centralized Unit (CU) and Distributed Unit (DU), which enables greater flexibility, scalability, and performance compared to previous generations of radio access networks.

In this article, we will discuss the technical aspects of the NG-RAN CU-DU split, including the architecture, functions, and benefits of the split, as well as the challenges and considerations associated with its deployment.

Architecture of the NG-RAN CU-DU Split

The NG-RAN CU-DU split separates the network functions of the radio access network into two distinct components: the Centralized Unit (CU) and the Distributed Unit (DU). The CU is responsible for performing the centralized control and management functions of the radio access network, while the DU is responsible for the distributed radio transmission and reception functions.

The CU and DU are connected by a standardized interface, known as the F1 interface, which enables communication and coordination between the two components. The CU-DU split can be further subdivided into different functional splits, depending on the specific network architecture and deployment scenario.

Functions of the NG-RAN CU-DU Split

The CU and DU perform different functions in the NG-RAN architecture, based on their respective roles in the radio access network.

The Centralized Unit (CU) is responsible for the following functions:

  1. Radio Resource Management (RRM): The CU is responsible for managing the radio resources, including the allocation of frequency, time, and power resources, to optimize the network performance and meet the quality of service (QoS) requirements.
  2. Mobility Management (MM): The CU is responsible for managing the mobility of the user devices, including handovers between cells, to ensure seamless connectivity and minimize disruption to the user experience.
  3. Session Management (SM): The CU is responsible for managing the establishment, maintenance, and termination of user sessions, including the allocation of IP addresses and other network resources.
  4. User Plane Function (UPF): The CU can also perform the user plane function, which involves processing and forwarding user data between the user device and the core network.

The Distributed Unit (DU) is responsible for the following functions:

  1. Radio Transmission and Reception (RTR): The DU is responsible for transmitting and receiving radio signals to and from the user devices, including the modulation and demodulation of the radio signals.
  2. Radio Link Control (RLC): The DU is responsible for managing the radio link control functions, including error detection and correction, retransmission, and flow control.
  3. Medium Access Control (MAC): The DU is responsible for managing the medium access control functions, including scheduling, resource allocation, and synchronization.

Benefits of the NG-RAN CU-DU Split

The NG-RAN CU-DU split provides several benefits compared to previous generations of radio access networks, including the following:

  1. Flexibility: The CU-DU split enables greater flexibility in network architecture and deployment, allowing network operators to tailor the network to specific use cases and requirements.
  2. Scalability: The CU-DU split enables greater scalability, allowing network operators to easily add or remove DU units to support changing network demand.
  3. Performance: The CU-DU split enables greater performance, by offloading some of the processing and management functions from the DU to the more powerful CU, and optimizing the radio transmission and reception functions at the DU.
  4. Efficiency: The CU-DU split enables greater efficiency, by enabling the optimization of radio resources and reducing the amount of signaling and data transmission between the DU and CU.

Challenges and Considerations for NG-RAN CU-DU Split Deployment

While the NG-RAN CU-DU split provides several benefits, there are also challenges and considerations associated with its deployment. Some of these challenges include the following:

  1. Interoperability: The CU and DU units are provided by different vendors, which can make it challenging to ensure interoperability and compatibility between different components.
  2. Synchronization: The CU-DU split requires precise synchronization between the different network elements, including the DU units, to ensure optimal network performance and minimize interference.
  3. Latency: The CU-DU split can introduce additional latency into the network, due to the increased signaling and data transmission between the CU and DU units.
  4. Network Optimization: The CU-DU split requires careful network planning and optimization to ensure that the different network functions are properly distributed between the CU and DU units, and that the network resources are effectively utilized.

To address these challenges, network operators and equipment vendors must work together to ensure the interoperability and compatibility of different network components, and to optimize the network performance and efficiency. This requires a deep understanding of the technical aspects of the CU-DU split, as well as the ability to implement and manage the network components in a highly coordinated and effective manner.

Conclusion

The NG-RAN CU-DU split is a key component of the 5G radio access network, providing greater flexibility, scalability, performance, and efficiency compared to previous generations of radio access networks. The CU-DU split separates the radio access network functions into two distinct components, the CU and DU, which are connected by a standardized interface. While the CU-DU split provides several benefits, it also presents challenges and considerations that must be carefully addressed to ensure optimal network performance and efficiency. Overall, the NG-RAN CU-DU split is an important development in the evolution of radio access networks, enabling the support of new use cases and applications, and driving innovation and growth in the telecommunications industry.
