5G New Radio in Unlicensed Spectrum

Introduction

5G New Radio (NR) technology aims to provide higher data rates, improved reliability, and lower latency. It has been designed to support a wide range of use cases such as mobile broadband, massive machine-type communication, and ultra-reliable and low-latency communication. One of the key enablers of 5G NR is the use of unlicensed spectrum. This allows 5G NR to operate in the same frequency bands as other unlicensed technologies such as Wi-Fi and Bluetooth.

In this article, we will discuss the technical aspects of 5G NR in unlicensed spectrum. We will start by discussing the different frequency bands that are available for unlicensed use and how they are regulated. We will then look at the key features of 5G NR that make it suitable for operation in unlicensed spectrum. Finally, we will discuss some of the challenges that need to be overcome to ensure successful deployment of 5G NR in unlicensed spectrum.

Frequency Bands for Unlicensed Use

There are several frequency bands that are available for unlicensed use. These bands are typically referred to as Industrial, Scientific, and Medical (ISM) bands. The most common ISM bands are:

  • 2.4 GHz band (2400-2483.5 MHz)
  • 5 GHz band (5150-5350 MHz and 5470-5725 MHz)
  • 60 GHz band (57-66 GHz)

In addition to the ISM bands, there are also other unlicensed bands such as the Citizens Broadband Radio Service (CBRS) band in the US and the Dynamic Spectrum Access (DSA) band in Europe.

The use of unlicensed spectrum is regulated by different regulatory bodies in different regions of the world. In the US, the Federal Communications Commission (FCC) regulates the use of unlicensed spectrum, while in Europe, it is the European Telecommunications Standards Institute (ETSI) that provides guidelines for the use of unlicensed spectrum.

Key Features of 5G NR in Unlicensed Spectrum

There are several key features of 5G NR that make it suitable for operation in unlicensed spectrum. These include:

  • Carrier Aggregation: 5G NR supports carrier aggregation, which allows multiple frequency bands to be used simultaneously to increase the data rate and capacity of the network. Carrier aggregation can be used to combine unlicensed and licensed frequency bands to provide wider coverage and higher data rates.
  • Dynamic Spectrum Sharing: 5G NR supports dynamic spectrum sharing (DSS), which allows the same frequency band to be shared between different technologies such as 4G LTE and 5G NR. DSS can be used to allocate spectrum dynamically between licensed and unlicensed technologies to ensure efficient use of the available spectrum.
  • Listen-Before-Talk: 5G NR supports listen-before-talk (LBT), which is a mechanism that ensures fair coexistence between different technologies using the same frequency band. LBT requires devices to listen to the channel before transmitting to avoid collisions with other devices.
  • Carrier Sensing Adaptive Transmission: 5G NR supports carrier sensing adaptive transmission (CSAT), which is a mechanism that allows devices to adjust their transmission power based on the level of interference in the channel. CSAT can be used to improve the efficiency of the network and reduce interference with other devices.
  • Short Transmission Time Interval: 5G NR supports a short transmission time interval (TTI) of 1 ms, which allows for low latency communication. This is particularly important for use cases such as autonomous vehicles and industrial automation, where low latency is critical.

Challenges of 5G NR in Unlicensed Spectrum

There are several challenges that need to be overcome to ensure successful deployment of 5G NR in unlicensed spectrum. These include:

  • Coexistence with other Technologies: One of the main challenges of deploying 5G NR in unlicensed spectrum is ensuring fair coexistence with other technologies such as Wi-Fi and Bluetooth. These technologies use the same frequency bands and have been deployed on a massive scale. It is important to ensure that 5G NR does not cause interference with existing Wi-Fi and Bluetooth networks and vice versa. To address this challenge, 5G NR supports mechanisms such as listen-before-talk (LBT) and carrier sensing adaptive transmission (CSAT) to ensure fair coexistence with other technologies.
  • Interference: Another challenge of deploying 5G NR in unlicensed spectrum is interference from other devices operating in the same frequency band. Interference can reduce the performance of the network and cause data errors. To address this challenge, 5G NR supports CSAT, which allows devices to adjust their transmission power based on the level of interference in the channel. In addition, 5G NR also supports beamforming and other advanced antenna technologies that can improve the signal-to-noise ratio and reduce interference.
  • Spectrum Availability: Unlicensed spectrum is a shared resource that is available to all users. This can lead to congestion and reduced performance, especially in densely populated areas. To address this challenge, 5G NR supports carrier aggregation, which allows multiple frequency bands to be used simultaneously to increase the capacity of the network. In addition, dynamic spectrum sharing (DSS) can be used to allocate spectrum dynamically between different technologies to ensure efficient use of the available spectrum.
  • Security: Unlicensed spectrum is open to all users, which makes it vulnerable to security threats such as unauthorized access and data breaches. To address this challenge, 5G NR supports advanced security features such as secure boot, secure communications, and device authentication. These features can help to prevent unauthorized access and ensure the security of the network and the data transmitted over it.

Conclusion

In conclusion, 5G NR in the unlicensed spectrum has the potential to provide high data rates, improved reliability, and low latency for a wide range of use cases. The key features of 5G NR such as carrier aggregation, dynamic spectrum sharing, listen-before-talk, carrier sensing adaptive transmission, and short transmission time interval make it suitable for operation in unlicensed spectrum. However, there are also several challenges that need to be addressed to ensure the successful deployment of 5G NR in the unlicensed spectrum. These challenges include fair coexistence with other technologies, interference, spectrum availability, and security. With the right solutions in place, 5G NR in the unlicensed spectrum has the potential to revolutionize wireless communication and bring about a new era of connectivity.
